LT1767EMS8-1.8#TR

Item No.:
LT1767EMS8-1.8#TR
Part number: LT1767EMS8-1.8#TR
Package: MSOP-8
Brand: LT
CONTACT US FOR PRICES AND MORE INFORMATION
Datasheet:
Quantity:
Delivery:
Payment:
RFQ List (0item)
In Stock : 13846
Please send RFQ, we will respond immediately.
-
+
LT1767EMS8-1.8#TR information
        The LT ®1767 is a 1.25MHz monolithic buck switching regulator. A high efficiency 1.5A, 0.22Ω switch is included on the die together with all the control circuitry required to complete a high frequency, current mode switching regu-lator. Current mode control provides fast transient re-sponse and excellent loop stability.
        New design techniques achieve high efficiency at high switching frequencies over a wide operating range. A low dropout internal regulator maintains consistent perfor-mance over a wide range of inputs from 24V systems to Li-Ion batteries. An operating supply current of 1mA im-proves efficiency, especially at lower output currents.Shutdown reduces quiescent current to 6 μA. Maximum switch current remains constant at all duty cycles. Syn-chronization allows an external logic level signal to in-crease the internal oscillator from 1.4MHz to 2MHz.
        The LT1767 is available in an 8-pin MSOP fused leadframe package and a low thermal resistance exposed pad pack-age. Full cycle-by-cycle short-circuit protection and ther-mal shutdown are provided. High frequency operation allows the reduction of input and output filtering compo-nents and permits the use of chip inductors.

FEATURES
1.5A Switch in a Small MSOP Package
Constant 1.25MHz Switching Frequency
High Power Exposed Pad (MS8E) Package
Wide Operating Voltage Range: 3V to 25V
High Efficiency 0.22Ω Switch
1.2V Feedback Reference Voltage
Fixed Output Voltages of 1.8V, 2.5V, 3.3V, 5V
2% Overall Output Tolerance
Uses Low Profile Surface Mount Components
Low Shutdown Current: 6μA
Synchronizable to 2MHz
Current Mode Loop Control
Constant Maximum Switch Current Rating at All Duty Cycles


The product is in the warehouse and can be shipped immediately

***************************************************************
FOR MORE DETAILS , PLEASE CONTACT US, THANK YOU.
